Programming: Correct setting of motion detectors
More space, easy handling, a clever concept 鈥 there are many reasons for Theben motion detectors to be installed and started up easier and faster. The best reasons you can find here.
Cover clips for detection area of motion detector theLuxa S360
In order to partially delimit the detection area, for instance in order to not detect movements on the neighbouring property, you can use cover clips on motion detector theLuxa S.
Increasing or decreasing the detection area of motion detector theLuxa S360
You can increase or decrease the detection area of motion detector theLuxa S360 by using the potentiometer labelled "Meter".
Test function of motion detector theLuxa S
By using the test function, the detection area of theLuxa motion detectors can be aligned quickly and precisely even in daylight.
Pulse function of motion detector theLuxa S
By using the pulse function, motion detector theLuxa S can be integrated into existing electrical installations, for instance to switch the staircase light.
Setting the lux value of motion detector theLuxa S
By using the potentiometer with the moon symbol, you can set the lux value at motion detector theLuxa, which allows you to individually determine under which lighting conditions the detector should respond.
Time delay of motion detector theLuxa S
By using the potentiometer showing the minutes, you can set the time delay at motion detector theLuxa. You can freely select a time delay between 5 seconds and 20 minutes.
Teach-In function of motion detector theLuxa S
If the desired lighting conditions are present, you activate the teach-in function at motion detector theLuxa, and the current lux value will be saved.
