RAMSES 784 HF Set 1

Description

Radio-controlled system for room temperature control
Consisting of one analogue clock thermostat RAMSES 784 HF and one REC 1 receiver with a two-way switch 6 (1) A/250 VDC
Tappet program disc with daily or weekly program
RAMSES 784 HF battery version
REC 1 mains version
Electronic temperature control
Normal and reduced temperature can be set separately
Quartz mechanism
Operating point and electronic recirculation are set from the front
Party switch and program display
Selector switch for operating mode: continuous reduced temperature, continuous normal temperature, automatic mode, frost and plant protection +6 掳C
Battery monitoring with battery replacement indicator via flashing LED
Silting and pump protection function (option)

Operating voltage	2 AA batteries
Type of contact	Changeover contact
Installation type	Wall installation
Program	Daily/weekly program
Switching capacity	6 A (at 250 V AC, cos 蠁 = 1), 1 A (at 250 V AC, cos 蠁 = 0.6)
Switching differential	0,4聽鈥撀�1,2 K
Switching output	Potential-free
Suitable for SELV	Yes
Setting range temperature	+10 掳C聽鈥β�+30 掳C
Shortest switching times	20 min, 120 min
Programmable every	5 min, 30 min
Time accuracy at 25 掳C	鈮� 卤 1 s/day (quartz)
Stand-by consumption	1,7 W
Battery life	approx. 1 year, depending on switching frequency
Colour	White
Type of protection	IP 20
Protection class	II according to EN 60 730-1
