Operating voltage |
110聽鈥撀240 V AC |
Frequency |
50聽鈥撀60 Hz |
Width |
4 modules |
Installation type |
DIN rail |
Type of contact |
Two-way switch |
Switching output |
Phase-independent |
Opening width |
< 3 mm |
Program |
Yearly program |
Number of channels |
4 |
External inputs |
4 |
Switching capacity at 250 V AC, cos 蠁 = 1 |
16 A |
Switching capacity channels 1+3
|
10 A |
Switching capacity at 250 V AC, cos 蠁 = 0,6 |
10 A |
Incandescent/halogen lamp load 230 V |
2300 W |
Incandescent/halogen lamp load 120 V |
1150 W |
Energy saving lamps 230 V |
22 x 7 W, 18 x 11 W |
Energy saving lamps 120 V |
11 x 7 W, 9 x 11 W |
Switching capacity min.
|
ca. 10 mA |
Stand-by consumption |
~1,5 W |
Capacity loss max. |
4,8 W |
Memory card supplied |
鈥 |
Type of connection |
DuoFix spring terminals |
Keyboards |
4 buttons for manual switching |
Housing and insulation material |
High-temperature resistant, self-extinguishing thermoplastic |
Type of protection |
IP 20 |
Protection class |
II according to EN 60 730-1 |
Ambient temperature |
-30 掳C聽鈥β+55 掳C |
